SEETEC ATEM156-CO 15.6 Inch Broadcast Director Monitor Carry on with 4 HDMI
$510.00
Features:
1. Full HD 1920x1080 resolution
2. HDMIX4 inputs and outputs3. Special Features:
* Quad Split Display (1P, 2P LR, 2P TB, 2P PIP, 4P)
* Peaking Focus Assist
* False Color
* Anamorphic (x1.33, x1.5, x1.8, x2.0)
* Display Rotate (0°, 90°, 180°, 270°, H Mirror, V Mirror)
* Check Field (Red, Green, Blue, Mono)
* Image Freeze
* Zoom
* pixel to Pixel
* Center Marker
* Safety Marker(80%, 85%, 90%, 93%, 96%, 4:3, 2.39:1, 2.35:1, 1.85:1)
* Line Color (Red, Green, Blue, White)4. Monitoring via front panel 3.5mm stereo headphone jack
Display Spec.
Screen Size: 15.6" IPS
Color Depth: 16.7M colors (8-bits)
Resolution: 1920×1080 pixels
Pixel Pitch: 0.17925 (H) X 0.17925 (V) mm
Aspect Ratio: 16:9
Brightness: 250cd/m²
Contrast Ratio: 800:1
Backlight: LED
Viewing Angle: 85°/85°(L/R) 85°/85°(U/D)
Input
4 X HDMI: HDMI (Support 4K 30Hz)
Output
4 X HDMI: HDMI (Support 4K 30Hz)
Audio
Audio Out: 3.5mm Stereo Headphone
HDMI Support Format
480i/576i/480p/576p
720p (60/59.94/50/30/29.97/25/24/23.98)
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/23.98)
3840×2160p (30/25/24), 4096×2160p (24)
General
Input Voltage: DC12~24V
Power Consumption: ≤12W
Working Temperature: -10°C~50°C
Storage Temperature: -20°C~60°C
Unit Size (mm): 372L×262H×28.4D (mm) (Without Aluminum Case)
Unit Weight: 1.57kg (Without Aluminum Case)
